• Enter the separate setting number [1-4] or [default] and specify the authentication algorithm,
and then set the authentication key.
•
If you are setting a hexadecimal number, attach 0x at the beginning.
• If you are setting an ASCII character string, enter it as is.
• Not specifying either the authentication algorithm or key displays the current setting. (The
authentication key is not displayed.)
Encryption algorithm and encryption key setting
msh> ipsec manual {1|2|3|4|default} encrypt {null|des|3des|aes128|aes192|
aes256} "encryption key"
• Enter the separate setting number [1-4] or [default], specify the encryption algorithm, and
then set the encryption key.
• If you are setting a hexadecimal number, attach 0x at the beginning. If you have set the
encryption algorithm to [null], enter an encryption key of arbitrary numbers 2-64 digits long.
• If you are setting an ASCII character string, enter it as is. If you have set the encryption
algorithm to [null], enter an encryption key of arbitrary numbers 1-32 digits long.
• Not specifying an encryption algorithm or key displays the current setting. (The encryption key
is not displayed.)
Reset setting values
msh> ipsec manual {1|2|3|4|default|all} clear
• Enter the separate setting number [1-4] or [default] and reset the specified setting. Specifying
[all] resets all of the settings, including default.
ipsec ike
To display or specify the encryption key auto exchange settings, use the "ipsec ike" command.
Display current settings
msh> ipsec ike {1|2|3|4|default}
• To display the settings 1-4, specify the number [1-4].
• To display the default setting, specify [default].
• Not specifying any value displays all of the settings.
Disable settings
msh> ipsec manual {1|2|3|4|default} disable
• To disable the settings 1-4, specify the number [1-4].
• To disable the default settings, specify [default].
Specify the local/remote address for settings 1-4
msh> ipsec manual {1|2|3|4} {ipv4|ipv6} "local address" "remote address"
Configuring IPsec
169

Ricoh Aficio MP C5502 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Max Print Resolution	1200 x 1200 dpi
Copy Resolution	600 x 600 dpi
Multiple Copy	Up to 999 copies
Max Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Hard Disk Drive	250 GB
Power Consumption (Maximum)	1.7 kW
Type	All in One Printer
Print Speed	55 pages per minute
Copy Speed	55 copies per minute
Zoom	25% to 400%
Scan Resolution	600 dpi
Fax Resolution	200 x 200 dpi
Original Capacity	100 sheets
Standard Paper Capacity	1, 200 sheets
Memory	1.5 GB RAM
Interface	USB 2.0, Ethernet
Network Protocols	TCP/IP
Operating Systems Supported	Windows, Mac, Linux
Power Source	AC 120V, 60Hz
Paper Weight	52 – 256 g/m²
