Ricoh Aficio MP C5502 User Manual

1. Log in as the network administrator from Web Image Monitor.
2. Point to [Device Management], and then click [Configuration].
3. Click [IPP Authentication] under "Security".
4. Select [DIGEST] from the "Authentication" list.
5. Enter the user name in the "User Name" box.
6. Enter the password in the "Password" box.
7. Click [OK].
IPP authentication is specified.
8. "Updating..." appears. Wait for about one or two minutes, and then click [OK].
9. Log out.
• When using the IPP port under Windows XP/Vista/7, Windows Server 2003/2003
R2/2008/2008 R2, you can use the operating system's standard IPP port.
Encrypting Transmitted Passwords
183

Ricoh Aficio MP C5502 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Max Print Resolution	1200 x 1200 dpi
Copy Resolution	600 x 600 dpi
Multiple Copy	Up to 999 copies
Max Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Hard Disk Drive	250 GB
Power Consumption (Maximum)	1.7 kW
Type	All in One Printer
Print Speed	55 pages per minute
Copy Speed	55 copies per minute
Zoom	25% to 400%
Scan Resolution	600 dpi
Fax Resolution	200 x 200 dpi
Original Capacity	100 sheets
Standard Paper Capacity	1, 200 sheets
Memory	1.5 GB RAM
Interface	USB 2.0, Ethernet
Network Protocols	TCP/IP
Operating Systems Supported	Windows, Mac, Linux
Power Source	AC 120V, 60Hz
Paper Weight	52 – 256 g/m²
