Ricoh Aficio MP C5502 User Manual

Error Code Cause Solution
W0406-104 4. Cannot resolve the domain name. Under Windows 7, if the Windows
firewall is activated, create a
firewall rule in the "Advanced
settings" on the "System and
security" control panel, and then
authorize ports 137 and 139.
Under Windows XP, if the Windows
firewall is activated, open the
properties for "Network
Connections", and then click
"Settings" on the "Advanced" tab.
On the "Exceptions" tab, specify
ports 137 and 139 as exceptions.
In the Properties window for
"Network Connections", open
TCP/IP properties. Then click detail
settings, WINS, and then check the
"Enable NetBIOS over TCP/IP" box
and set number 137 to "Open".
8. Troubleshooting
288

Ricoh Aficio MP C5502 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Max Print Resolution	1200 x 1200 dpi
Copy Resolution	600 x 600 dpi
Multiple Copy	Up to 999 copies
Max Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Hard Disk Drive	250 GB
Power Consumption (Maximum)	1.7 kW
Type	All in One Printer
Print Speed	55 pages per minute
Copy Speed	55 copies per minute
Zoom	25% to 400%
Scan Resolution	600 dpi
Fax Resolution	200 x 200 dpi
Original Capacity	100 sheets
Standard Paper Capacity	1, 200 sheets
Memory	1.5 GB RAM
Interface	USB 2.0, Ethernet
Network Protocols	TCP/IP
Operating Systems Supported	Windows, Mac, Linux
Power Source	AC 120V, 60Hz
Paper Weight	52 – 256 g/m²
