SM 7-3 G147
Specifications
installed.
Dimensions (W x D x H): 670 x 640 x 560 mm (26.4" x 25.2" x 22.0")
With Optional LCIT 820 x 640 x 560 mm (32.3" x 25.2" x 22.0")
Duplexer closed 670 x 650 mm (26.4 x 25.6 in.)
Duplexer open 910 x 650 mm (36.8 x 25.6 in.)
Bypass closed 670 x 650 mm (26.4 x 25.6 in.)
Bypass tray open 850 x 650 mm (33.5 x 25.6 in.)
Footprint (W x D)
Bypass tray support
extended
980 x 650 mm (38.6 x 25.6 in.)
Temperature: Operating:
10°~32°C (50°~89.6°F), 15%~80% rH (no condensation)
Storage:
30°C ~ 40°C (22°~104°F), less than 80% rH (no
condensation)
Weight: Less than 63 kg (138.9 lb.)
Warm-up Time: At power on
Less than 22 s at 20°C (68°F)
From Energy Save
mode
Less than 15 s at 20°C (68°F)
Paper Feed Method: FRR method (paper trays and bypass tray)
First Print: Less than 6 sec. (A4 LEF, 1st feed)
500 sheets x 2 1000
50 sheets (Bypass Tray) x 1 50
Printer only 1050
550 sheets (optional PTU) x2 1100
Paper Capacity:
1500 sheets (optional LCT) 1500
