SC No. Level Error Name/Error Condition/Major Cause/Solution
SC502-01 B 2nd Tray Lift Error
The 2nd tray lift motor error detection count reaches 3.
(Up to 2, reset is displayed)
• 2nd tray limit sensor connector missing, malfunction, dirt
• 2nd tray lift motor connector missing, disconnection, malfunction
• Foreign matter, such as paper scrap, is caught between the paper
feed tray and the tray lift motor
• Paper set fault
• Reset the paper
• Remove the foreign matter
2nd tray limit sensor, 2nd tray lift motor
• Check the harness
• Reset the connector
• Replacement
2nd paper feed unit, 2nd tray
• Replacement
Paper transport IOB
• Replacement
5. Troubleshooting
476
