SC No. Level Error Name/Error Condition/Major Cause/Solution
SC723-20 B
Junction Solenoid Motor Error (Internal Finisher: Non-Staple Bind)
When the junction claw HP sensor was not turned off while T3[msec]
applied to the solenoid motor with the HP sensor turned on.
When the junction claw HP sensor was not turned on while T4[msec]
applied to the solenoid motor with the HP sensor turned off.
This SC will be issued when the above phenomenon repeated 2 times.
• Junction Solenoid Motor failure
• Connector disconnected
• Over load
• Junction claw HP sensor error
• Check the connection
• Replace the motor/sensor
• Replace the harness
SC723-24 B
Exit Pressure Release Motor Error (Internal Finisher: Non-Staple Bind)
When the exit pressure release HP sensor was not turned off while
T5[msec] applied to the exit pressure release motor with the HP sensor
turned on.
When exit pressure release HP sensor was not turned on while T6[msec]
applied to the exit pressure release motor with the HP sensor turned off.
This SC will be issued when the above phenomenon repeated 2 times.
• Exit Pressure Release Motor failure
• Connector disconnected
• Over load
• Exit pressure release HP sensor error
• Check the connection
• Replace the motor/sensor
• Replace the harness
5. Troubleshooting
542
