Paper stack mechanism for stapling
The maximum thickness of the stack is 50 sheets for the conventional stapler, and 5 sheets for the
stapleless stapler.
In order for the stapleless stapler to stack the paper smoothly, cam [C] and paper guide [B] adjusts the
gap [A] of the stapler tray [E].
The cam [C] controlled by the Paper Guide Drive Motor (STM18) [D] pushes the paper guide [B] down
during the stapleless staple operation.
