Rigol DS1104Z Programming Guide

RIGOL Chapter 2 Command System
2-86 DS1000Z Programming Guide
:TRIGger:EDGe
Command List:
 :TRIGger:EDGe:SOURce
 :TRIGger:EDGe:SLOPe
 :TRIGger:EDGe:LEVel
:TRIGger:EDGe:SOURce
Syntax :TRIGger:EDGe:SOURce <source>
:TRIGger:EDGe:SOURce?
Description
Set or query the trigger source in edge trigger.
Parameter
Name
Type
Range
Default
<source> Discrete {CHANnel1|CHANnel2|CHANnel3|CHANnel4|AC} CHANnel1
Return
Format
The query returns CHAN1, CHAN2, CHAN3, CHAN4 or AC.
Example
:TRIGger:EDGe:SOURce CHANnel1
:TRIGger:EDGe:SLOPe
Syntax :TRIGger:EDGe:SLOPe <slope>
:TRIGger:EDGe:SLOPe?
Description
Set or query the edge type in edge trigger.
Parameter
Name
Type
Range
Default
<slope>
Discrete
{POSitive|NEGative|RFALl}
POSitive
Return
Format
The query returns POS, NEG or RFAL.
Example
:TRIGger:EDGe:SLOPe NEGative
Related
Command
:TRIGger:MODE

Rigol DS1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Interface	USB Host, USB Device, LAN, AUX
Display	7 inch TFT LCD (800 x 480)
Trigger Types	Edge, Pulse, Video, Slope
Power Supply	100-240 V, 45-440 Hz
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
