Rigol DS1104Z Programming Guide

Chapter 2 Command System RIGOL
DS1000Z Programming Guide 2-99
:TRIGger:PATTern
Command List:
 :TRIGger:PATTern:PATTern
 :TRIGger:PATTern:LEVel
:TRIGger:PATTern:PATTern
Syntax :TRIGger:PATTern:PATTern <pattern1>,<pattern2>,<pattern3>,<pattern4>
:TRIGger:PATTern:PATTern?
Description
Set or query the pattern of each channel in pattern trigger.
Parameter
Name
Type
Range
Default
<pattern1>
Discrete
{H|L|X|R|F}
X
<pattern2>
Discrete
{H|L|X|R|F}
X
<pattern3>
Discrete
{H|L|X|R|F}
X
<pattern4>
Discrete
{H|L|X|R|F}
X
Explanation  H: set the pattern of the channel selected to “H”, namely the voltage level is higher
than the threshold level of the channel.
 L: set the pattern of the channel selected to “L”, namely the voltage level is lower
than the threshold level of the channel.
 X: set the pattern of the channel selected to “Don’t Care”, namely this channel is not
used as a part of the pattern. When all the four channels in the pattern are set to
“Don’t Care”, the oscilloscope will not trigger.
 R/F: set the pattern to the rising or falling edge of the channel selected.
 You can not to specify the patterns of two channels to the rising edge or falling edge
at the same time. If one edge item is currently defined and then another edge item is
defined in another channel in the pattern, the former edge item defined will be
replaced by X.
 The four parameters from left to right in the command set the patterns of CH1, CH2,
CH3 and CH4 respectively.
Return
Format
The query returns the patterns of all the channels.
Example
:TRIGger:PATTern:PATTern H,R,L,X

Rigol DS1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Interface	USB Host, USB Device, LAN, AUX
Display	7 inch TFT LCD (800 x 480)
Trigger Types	Edge, Pulse, Video, Slope
Power Supply	100-240 V, 45-440 Hz
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
