Rigol DS1104Z Programming Guide

Chapter 2 Command System RIGOL
DS1000Z Programming Guide 2-47
:MASK:SOURce
Syntax :MASK:SOURce <source>
:MASK:SOURce?
Description
Set or query the source of the pass/fail test.
Parameter
Name
Type
Range
Default
<source>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel1
Explanation Only the channel enabled can be selected as the source. You can sent
the :CHANnel<n>:DISPlay command to enable the desired channel.
Return
Format
The query returnsCHAN1, CHAN2, CHAN3 or CHAN4.
Example
:MASK:SOURce CHANnel2
Related
Command
:CHANnel<n>:DISPlay
:MASK:OPERate
Syntax :MASK:OPERate <oper>
:MASK:OPERate?
Description
Run or stop the pass/fail test, or query the status of the pass/fail test.
Parameter
Name
Type
Range
Default
<oper>
Discrete
{RUN|STOP}
STOP
Explanation Before executing this command, you need to send the :MASK:ENABle command to enable
the pass/fail test.
Return
Format
The query returns RUN or STOP.
Example
:MASK:OPERate RUN
Related
Command
:MASK:ENABle

Rigol DS1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Interface	USB Host, USB Device, LAN, AUX
Display	7 inch TFT LCD (800 x 480)
Trigger Types	Edge, Pulse, Video, Slope
Power Supply	100-240 V, 45-440 Hz
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
