Rigol DS1104Z Programming Guide

RIGOL Chapter 2 Command System
2-116 DS1000Z Programming Guide
:TRIGger:SHOLd (Option)
Command List:
 :TRIGger:SHOLd:DSrc
 :TRIGger:SHOLd:CSrc
 :TRIGger:SHOLd:SLOPe
 :TRIGger:SHOLd:PATTern
 :TRIGger:SHOLd:TYPe
 :TRIGger:SHOLd:STIMe
 :TRIGger:SHOLd:HTIMe
:TRIGger:SHOLd:DSrc
Syntax :TRIGger:SHOLd:DSrc <source>
:TRIGger:SHOLd:DSrc?
Description
Set or query the data source in setup/hold trigger.
Parameter
Name
Type
Range
Default
<source> Discrete {CHANnel1|CHANnel2|CHANnel3|CHANnel4} CHANnel1
Return
Format
The query returns CHAN1, CHAN2, CHAN3 or CHAN4.
Example
:TRIGger:SHOLd:DSrc CHANnel1
:TRIGger:SHOLd:CSrc
Syntax :TRIGger:SHOLd:CSrc <source>
:TRIGger:SHOLd:CSrc?
Description
Set or query the clock source in setup/hold trigger.
Parameter
Name
Type
Range
Default
<source> Discrete {CHANnel1|CHANnel2|CHANnel3|CHANnel4} CHANnel2
Return
Format
The query returns CHAN1, CHAN2, CHAN3 or CHAN4.
Example
:TRIGger:SHOLd:CSrc CHANnel2
:TRIGger:SHOLd:SLOPe
Syntax :TRIGger:SHOLd:SLOPe <slope>
:TRIGger:SHOLd:SLOPe?
Description
Set or query the edge type in setup/hold trigger.
Parameter
Name
Type
Range
Default
<slope>
Discrete
{POSitive|NEGative}
POSitive
Return
Format
The query returns POS or NEG.
Example
:TRIGger:SHOLd:SLOPe NEGative

Rigol DS1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Interface	USB Host, USB Device, LAN, AUX
Display	7 inch TFT LCD (800 x 480)
Trigger Types	Edge, Pulse, Video, Slope
Power Supply	100-240 V, 45-440 Hz
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
