RIGOL Chapter 2 Command System
2-138 DS1000Z Programming Guide
:WAVeform:YINCrement?
Syntax
:WAVeform:YINCrement?
Description Query the waveform increment of the specified channel source in the Y direction. The unit
is the same as the current amplitude unit.
Explanation YINCrement= VerticalScale/25
Return
Format
The query returns the YINCrement in scientific notation.
Example
:WAVeform:YINCrement? /*The query returns 8.000000e-03*/
Related
Command
:WAVeform:SOURce
:WAVeform:YORigin?
Syntax
:WAVeform:YORigin?
Description Query the vertical offset relative to the vertical reference position of the specified channel
source in the Y direction.
Explanation
YORigin = VerticalOffset/YINCrement.
Return
Format
The query returns an integer.
Example
:WAVeform:YORigin? /*The query returns 0*/
Related
Commands
:WAVeform:SOURce
:WAVeform:YREFerence?
:WAVeform:YREFerence?
Syntax
:WAVeform:YREFerence?
Description
Query the vertical reference position of the specified channel source in the Y direction.
Explanation
The YREFerence is fixed at 127 (the bottom of the screen is 0 and the top is 255).
Return
Format
The query returns an integer.
Related
Command
:WAVeform:SOURce

Rigol DS1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Interface	USB Host, USB Device, LAN, AUX
Display	7 inch TFT LCD (800 x 480)
Trigger Types	Edge, Pulse, Video, Slope
Power Supply	100-240 V, 45-440 Hz
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
