Chapter 2 Command System RIGOL
DS1000Z Programming Guide 2-71
[:SOURce[<n>]]:VOLTage[:LEVel][:IMMediate]:OFFSet
Syntax [:SOURce[<n>]]:VOLTage[:LEVel] [:IMMediate]:OFFSet <offset>
[:SOURce[<n>]]:VOLTage[:LEVel] [:IMMediate]:OFFSet?
Description
Set or query the DC offset of the specified source channel. The default unit is V.
Parameter
Name
Type
Range
Default
[<n>] Discrete {1|2}
If omitted, the operation
is performed on source 1
by default
<offset> Real
Related to the output impedance
and amplitude:
HighZ: ±(2.5V-current amplitude/2)
50Ω: ±(1.25V-current amplitude/2)
0V
Explanation  You can use the [:SOURce[<n>]]:OUTPut[<n>]:IMPedance command to set the
output impedance.
 You can use the
[:SOURce[<n>]]:VOLTage[:LEVel][:IMMediate][:AMPLitude]
command to set the output amplitude.
Return
Format
The query returns the DC offset in scientific notation, such as 1.0000000e+00.
Example
:VOLTage:OFFSet 0.5
[:SOURce[<n>]]:PULSe:DCYCle
Syntax [:SOURce[<n>]]:PULSe:DCYCle <percent>
[:SOURce[<n>]]:PULSe:DCYCle?
Description Set or query the pulse duty cycle (the percentage that the high level takes up in the whole
period) of the specified source channel. The default unit is %.
Parameter
Name
Type
Range
Default
[<n>] Discrete {1|2}
If omitted, the operation is
performed on source 1 by
default
<percent>
Real
10 to 90
20
Return
Format
The query returns the duty cycle in scientific notation, such as 5.000000e+01.
Example
:PULSe:DCYCle 50
Related
Command
[:SOURce[<n>]]:FUNCtion[:SHAPe]
