:MATH:OPTion:THReshold1
Syntax :MATH:OPTion:THReshold1 <thre>
:MATH:OPTion:THReshold1?
Description
Set or query the threshold level of source A in the logic operation. The default unit is V.
Parameter
Name
Type
Range
Default
<thre> Real
(-4*Vertical Scale – Vertical Offset) to
(4*Vertical Scale – Vertical Offset)
0.00V
Explanation  This command is only applicable to the logic operations (A&&B, A||B, A^B and !A).
 Vertical Scale refers to the vertical scale of source A
Vetical Offset refers to the vertical offset of source A
The step is Vertical Scale/25
Return
Format
The query returns the threshold level in scientific notation.
Example
:MATH:OPTion:THReshold1 0.8 /*Set the threshold level to 800mV*/
:MATH:OPTion:THReshold1? /*The query returns 8.000000e-01*/
Related
Commands
:CHANnel<n>:SCALe
:CHANnel<n>:OFFSet
:MATH:OPTion:THReshold2
Syntax :MATH:OPTion:THReshold2 <thre>
:MATH:OPTion:THReshold2?
Description
Set or query the threshold level of source B in the logic operation. The default unit is V.
Parameter
Name
Type
Range
Default
<thre>
Real
(-4*Vertical Scale–Vertical Offset) to
(4*Vertical Scale–Vertical Offset)
0.00V
Explanation  This command is only applicable to the logic operations (A&&B, A||B, A^B and !A).
 Vertical Scale refers to the vertical scale of source B
Vetical Offset refers to the vertical offset of source B
The step is Vertical Scale/25
Return
Format
The query returns the threshold level in scientific notation.
Example
:MATH:OPTion:THReshold2 0.5
Related
Commands
:CHANnel<n>:SCALe
:CHANnel<n>:OFFSet

Rigol DS1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Interface	USB Host, USB Device, LAN, AUX
Display	7 inch TFT LCD (800 x 480)
Trigger Types	Edge, Pulse, Video, Slope
Power Supply	100-240 V, 45-440 Hz
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
