Rigol DS1104Z Programming Guide

Chapter 2 Command System RIGOL
DS1000Z Programming Guide 2-63
:REFerence Commands
Command List:
 :REFerence:DISPlay
 :REFerence<n>:ENABle
 :REFerence<n>:SOURce
 :REFerence<n>:VSCale
 :REFerence<n>:VOFFset
 :REFerence<n>:RESet
:REFerence:DISPlay
Syntax :REFerence:DISPlay <onoff>
:REFerence:DISPlay?
Description
Enable or disable the REF function, or query the status of the REF function.
Parameter
Name
Type
Range
Default
<onoff> Bool {{0|OFF}|{1|ON}} 0|OFF
Return
Format
The query returns 0 or 1.
Example
:REFerence:DISPlay ON
:REFerence<n>:ENABle
Syntax :REFerence<n>:ENABle <bool>
:REFerence<n>:ENABle?
Description Enable or disable the specified reference channel, or query the status of the specified
reference channel.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2|3|4|5|6|7|8|9|10}
1
<bool> Bool {{0|OFF}|{1|ON}}
Ref1: 1|ON
Others: 0|OFF
Return
Format
The query returns 0 or 1.
Example
:REFerence1:ENABle ON

Rigol DS1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Interface	USB Host, USB Device, LAN, AUX
Display	7 inch TFT LCD (800 x 480)
Trigger Types	Edge, Pulse, Video, Slope
Power Supply	100-240 V, 45-440 Hz
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
