Chapter 2 Command System RIGOL
DS1000Z Programming Guide 2-119
:TRIGger:NEDGe (Option)
Command List:
 :TRIGger:NEDGe:SOURce
 :TRIGger:NEDGe:SLOPe
 :TRIGger:NEDGe:IDLE
 :TRIGger:NEDGe:EDGE
 :TRIGger:NEDGe:LEVel
:TRIGger:NEDGe:SOURce
Syntax :TRIGger:NEDGe:SOURce <source>
:TRIGger:NEDGe:SOURce?
Description
Set or query the trigger source in Nth edge trigger.
Parameter
Name
Type
Range
Default
<source>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel1
Return
Format
The query returns CHAN1, CHAN2, CHAN3 or CHAN4.
Example
:TRIGger:NEDGe:SOURce CHANnel2
:TRIGger:NEDGe:SLOPe
Syntax :TRIGger:NEDGe:SLOPe <slope>
:TRIGger:NEDGe:SLOPe?
Description
Set or query the edge type in Nth edge trigger.
Parameter
Name
Type
Range
Default
<slope>
Discrete
{POSitive|NEGative}
POSitive
Explanation  POSitive: trigger on the rising edge of the input signal when the voltage level meets
the specified trigger level.
 NEGative: trigger on the falling edge of the input signal when the voltage level meets
the specified trigger level.
Return
Format
The query returns POS or NEG.
Example
:TRIGger:NEDGe:SLOPe NEGative
