RIGOL Chapter 2 Command System
2-44 DS1000Z Programming Guide
:MATH:OPTion:SENSitivity
Syntax :MATH:OPTion:SENSitivity <sens>
:MATH:OPTion:SENSitivity?
Description Set or query the sensitivity of the logic operation. The default unit is div (namely the
current vertical scale).
Parameter
Name
Type
Range
Default
<sens>
Real
0 to 0.96div, the step is 0.08div
0
Explanation
This command is only applicable to the logic operations (A&&B, A||B, A^B and !A).
Return Format
The query returns the sensitivity in scientific notation.
Example :MATH:OPTion:SENSitivity 0.24 /*Set the sensitivity to 0.24div*/
:MATH:OPTion:SENSitivity? /*The query returns 2.400000e-01*/
Related
Commands
:CHANnel<n>:SCALe
:MATH:OPERator
:MATH:OPTion:DIStance
Syntax :MATH:OPTion:DIStance <dist>
:MATH:OPTion:DIStance?
Description
Set or query the smoothing window width of the differential operation (diff).
Parameter
Name
Type
Range
Default
<dist>
Integer
3 to 201
3
Explanation
This command is only applicable to the differential operation (diff).
Return Format
The query returns an integer between 3 and 201.
Example :MATH:OPTion:DIStance 25
Related
Command
:MATH:OPERator
:MATH:OPTion:ASCale
Syntax :MATH:OPTion:ASCale <opt>
:MATH:OPTion:ASCale?
Description Enable or disable the auto scale setting of the operation result or query the status of
the auto scale setting.
Parameter
Name Type Range Default
<opt>
Bool
{{0|OFF}|{1|ON}}
0|OFF
Explanation  When the auto scale is enabled, the instrument will automatically calculate the
vertical scale range according to the current operator, the vertical scale and the
horizontal timebase. If the current scale is out of the range, it will adjust the
vertical scale to the best value automatically.
 Sending this command will modify the auto scale status of all the operations.
Return Format
The query returns 0 or 1.
Example
:MATH:OPTion:ASCale ON

Rigol DS1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Interface	USB Host, USB Device, LAN, AUX
Display	7 inch TFT LCD (800 x 480)
Trigger Types	Edge, Pulse, Video, Slope
Power Supply	100-240 V, 45-440 Hz
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
