Rigol DS1104Z Programming Guide

Chapter 2 Command System RIGOL
DS1000Z Programming Guide 2-125
:TRIGger:IIC (Option)
Command List:
 :TRIGger:IIC:SCL
 :TRIGger:IIC:SDA
 :TRIGger:IIC:WHEN
 :TRIGger:IIC:AWIDth
 :TRIGger:IIC:ADDRess
 :TRIGger:IIC:DIRection
 :TRIGger:IIC:DATA
 :TRIGger:IIC:CLEVel
 :TRIGger:IIC:DLEVel
:TRIGger:IIC:SCL
Syntax :TRIGger:IIC:SCL <source>
:TRIGger:IIC:SCL?
Description
Set or query the channel source of SCL in I2C trigger.
Parameter
Name
Type
Range
Default
<source>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel1
Return
Format
The query returns CHAN1, CHAN2, CHAN3 or CHAN4.
Example
:TRIGger:IIC:SCL CHANnel2
:TRIGger:IIC:SDA
Syntax :TRIGger:IIC:SDA <source>
:TRIGger:IIC:SDA?
Description Set or query the channel source of SDA in I2C trigger.
Parameter
Name
Type
Range
Default
<source>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel2
Return
Format
The query returns CHAN1, CHAN2, CHAN3 or CHAN4.
Example
:TRIGger:IIC:SDA CHANnel2
