RIGOL Chapter 2 Command System
2-128 DS1000Z Programming Guide
:TRIGger:IIC:CLEVel
Syntax :TRIGger:IIC:CLEVel <level>
:TRIGger:IIC:CLEVel?
Description Set or query the trigger level of SCL in I2C trigger. The unit is the same as the
current amplitude unit.
Parameter
Name
Type
Range
Default
<level> Real (± 5 × VerticalScale from the screen center) - OFFSet 0
Explanation For VerticalScale, refer to :CHANnel<n>:SCALe. For OFFSet, refer
to :CHANnel<n>:OFFSet.
Return Format
The query returns the trigger level of SCL in scientific notation.
Example :TRIGger:IIC:CLEVel 0.16 /*Set the trigger level of SCL to 160mV*/
:TRIGger:IIC:CLEVel? /*The query returns 1.600000e-01*/
Related
Commands
:CHANnel<n>:SCALe
:CHANnel<n>:OFFSet
:TRIGger:IIC:DLEVel
Syntax :TRIGger:IIC:DLEVel <level>
:TRIGger:IIC:DLEVel?
Description Set or query the trigger level of SDA in I2C trigger. The unit is the same as the
current amplitude unit.
Parameter
Name Type Range Default
<level>
Real
(± 5 × VerticalScale from the screen center) - OFFSet
0
Explanation For VerticalScale, refer to :CHANnel<n>:SCALe. For OFFSet, refer
to :CHANnel<n>:OFFSet.
Return Format
The query returns the trigger level of SDA in scientific notation.
Example :TRIGger:IIC:DLEVel 0.16 /*Set the trigger level of SDA to 160mV*/
:TRIGger:IIC:DLEVel? /*The query returns 1.600000e-01*/
Related
Commands
:CHANnel<n>:SCALe
:CHANnel<n>:OFFSet
