Chapter 2 Command System RIGOL
DS1000Z Programming Guide 2-37
:MATH:DISPlay
Syntax :MATH:DISPlay <bool>
:MATH:DISPlay?
Description
Enable or disable the math operation function or query the math operation status.
Parameter
Name
Type
Range
Default
<bool>
Bool
{{0|OFF}|{1|ON}}
0|OFF
Return
Format
The query returns 0 or 1.
Example
:MATH:DISPlay ON
:MATH:OPERator
Syntax :MATH:OPERator <opt>
:MATH:OPERator?
Description
Set or query the operator of the math operation.
Parameter
Name
Type
Range
Default
<opt> Discrete {ADD|SUBTract|MULTiply|DIVision|AND|OR|XOR|
NOT|FFT|INTG|DIFF|SQRT|LOG|LN|EXP|ABS}
ADD
Return
Format
The query returns ADD, SUBT, MULT, DIV, AND, OR, XOR, NOT, FFT, INTG, DIFF, SQRT,
LOG, LN, EXP or ABS.
Example
:MATH:OPERator INTG
:MATH:SOURce1
Syntax :MATH:SOURce1 <src>
:MATH:SOURce1?
Description
Set or query the source of the math operation.
Parameter
Name
Type
Range
Default
<src>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel1
Explanation  For the operations which needs only one source, just this command will be used.
 For the operations which needs two sources, this command is used to set source A.
Return
Format
The query returns CHAN1, CHAN2, CHAN3 or CHAN4.
Example
:MATH:SOURce1 CHANnel3
