Rigol DS1104Z Programming Guide

RIGOL Chapter 2 Command System
2-16 DS1000Z Programming Guide
:CURSor:MANual
Command List:
 :CURSor:MANual:TYPE
 :CURSor:MANual:SOURce
 :CURSor:MANual:TUNit
 :CURSor:MANual:VUNit
 :CURSor:MANual:AX
 :CURSor:MANual:BX
 :CURSor:MANual:AY
 :CURSor:MANual:BY
 :CURSor:MANual:AXValue?
 :CURSor:MANual:AYValue?
 :CURSor:MANual:BXValue?
 :CURSor:MANual:BYValue?
 :CURSor:MANual:XDELta?
 :CURSor:MANual:IXDELta?
 :CURSor:MANual:YDELta?
:CURSor:MANual:TYPE
Syntax :CURSor:MANual:TYPE <type>
:CURSor:MANual:TYPE?
Description
Set or query the cursor type in manual cursor measurement mode.
Parameter
Name
Type
Range
Default
<type>
Discrete
{X|Y}
X
Explanation  X: select the X type cursors. The X type cursors are a vertical solid line (cursor A) and
a vertical dotted line (cursor B) and are usually used to measure the time
parameters.
 Y: select the Y type cursors. The Y type cursors are a horizontal solid line (cursor A)
and a horizontal dotted line (cursor B) and are usually used to measure the voltage
parameters.
Return
Format
The query returns X or Y.
Example :CURSor:MANual:TYPE Y /*select the Y type cursors*/

Rigol DS1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Interface	USB Host, USB Device, LAN, AUX
Display	7 inch TFT LCD (800 x 480)
Trigger Types	Edge, Pulse, Video, Slope
Power Supply	100-240 V, 45-440 Hz
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
