Rigol DS1104Z Programming Guide

Chapter 2 Command System RIGOL
DS1000Z Programming Guide 2-19
:CURSor:MANual:BY
Syntax :CURSor:MANual:BY <y>
:CURSor:MANual:BY?
Description
Set or query the vertical position of cursor B in the manual cursor measurement mode.
Parameter
Name
Type
Range
Default
<y> Integer 5 to 394 300
Explanation The horizontal and vertical positions of the cursor are defined by the pixel coordinate of
the screen. The pixel coordinate of the screen ranges from (0,0) to (600,400). Wherein,
(0,0) is located at the left top corner of the screen and (600,400) is located at the right
bottom corner of the screen. The horizontal pixel range is from 0 to 600 and the vertical
pixel range is from 0 to 400.
Return
Format
The query returns an integer between 5 and 394.
Example
:CURSor:MANual:BY 200 /*Set the vertical position of cursor B to 200*/
:CURSor:MANual:AXValue?
Syntax
:CURSor:MANual:AXValue?
Description Query the X value of cursor A in the manual cursor measurement mode. The unit depends
on the horizontal unit currently selected.
Return
Format
The query returns the X value of cursor A in scientific notation.
Example
:CURSor:MANual:AXValue? /*The query returns -3.000000e-06*/
Related
Commands
:CURSor:MANual:AX
:CURSor:MANual:TUNit
:CURSor:MANual:AYValue?
Syntax
:CURSor:MANual:AYValue?
Description Query the Y value of cursor A in the manual cursor measurement mode. The unit depends
on the vertical unit currently selected.
Return
Format
The query returns the Y value of cursor A in scientific notation.
Example
:CURSor:MANual:AYValue? /*The query returns -4.000000e-06*/
Related
Commands
:CURSor:MANual:AY
:CURSor:MANual:VUNit
:CURSor:MANual:BXValue?
Syntax
:CURSor:MANual:BXValue?
Description Query the X value of cursor B in the manual cursor measurement mode. The unit depends
on the horizontal unit currently selected.
Return
Format
The query returns the X value of cursor B in scientific notation.
Example
:CURSor:MANual:BXValue? /*The query returns -3.000000e-06*/
Related
Commands
:CURSor:MANual:BX
:CURSor:MANual:TUNit

Rigol DS1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Interface	USB Host, USB Device, LAN, AUX
Display	7 inch TFT LCD (800 x 480)
Trigger Types	Edge, Pulse, Video, Slope
Power Supply	100-240 V, 45-440 Hz
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
