RIGOL Chapter 2 Command System
2-20 DS1000Z Programming Guide
:CURSor:MANual:BYValue?
Syntax
:CURSor:MANual:BYValue?
Description Query the Y value of cursor B in the manual cursor measurement mode. The unit depends
on the vertical unit currently selected.
Return
Format
The query returns the Y value of cursor B in scientific notation.
Example
:CURSor:MANual:BYValue? /*The query returns-4.000000e-06*/
Related
Commands
:CURSor:MANual:BY
:CURSor:MANual:VUNit
:CURSor:MANual:XDELta?
Syntax
:CURSor:MANual:XDELta?
Description Query the difference between the X values of cursor A and cursor B (BX-AX) in the manual
cursor measurement mode. The unit depends on the horizontal unit currently selected.
Return
Format
The query returns the difference in scientific notation.
Example
:CURSor:MANual:XDELta? /*The query returns 6.120000e-06*/
Related
Commands
:CURSor:MANual:AX
:CURSor:MANual:BX
:CURSor:MANual:TUNit
:CURSor:MANual:IXDELta?
Syntax
:CURSor:MANual:IXDELta?
Description Query the reciprocal of the absolute value of the difference between the X values of cursor
A and cursor B (1/|dX|) in the manual cursor measurement mode. The unit depends on
the horizontal unit currently selected.
Return
Format
The query returns 1/|dX| in scientific notation.
Example
:CURSor:MANual:IXDELta? /*The query returns 1.120000e+05*/
Related
Commands
:CURSor:MANual:AX
:CURSor:MANual:BX
:CURSor:MANual:TUNit
:CURSor:MANual:YDELta?
Syntax
:CURSor:MANual:YDELta?
Description Query the difference between the Y values of cursor A and cursor B (BY-AY) in the manual
cursor measurement mode. The unit depends on the vertical unit currently selected.
Return
Format
The query returns the difference in scientific notation.
Example
:CURSor:MANual:YDELta? /*The query returns -4.700000e+00*/
Related
Commands
:CURSor:MANual:AY
:CURSor:MANual:BY
:CURSor:MANual:VUNit

Rigol DS1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Interface	USB Host, USB Device, LAN, AUX
Display	7 inch TFT LCD (800 x 480)
Trigger Types	Edge, Pulse, Video, Slope
Power Supply	100-240 V, 45-440 Hz
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
