RIGOL Chapter 2 Command System
2-38 DS1000Z Programming Guide
:MATH:SOURce2
Syntax :MATH:SOURce2 <src>
:MATH:SOURce2?
Description
Set or query the source of the math operation.
Parameter
Name
Type
Range
Default
<src>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel1
Explanation This command is only applicable to the operations which needs two source and it is used
to set source B.
Return
Format
The query returnsCHAN1, CHAN2, CHAN3 or CHAN4.
Example
:MATH:SOURce2 CHANnel3
:MATH:SCALe
Syntax :MATH:SCALe <scale>
:MATH:SCALe?
Description Set or query the vertical scale of the operation result. The unit depends on the operator
currently selected and the unit of the source.
Parameter
Name
Type
Range
Default
<scale> Real The max range is from 1p to 5T (in 1-2-5 step) 1.00V
Explanation The range of the vertical scale is related to the operator currently selected and the vertical
scale of the source channel. For the integration (intg) and differential (diff) operations, it
is also related to the current horizontal timebase.
Return
Format
The query returns the vertical scale of the operation result in scientific notation.
Example
:MATH:SCALe 2 /*Set the vertical scale to 2*/
:MATH:SCALe? /*The query returns 2.000000e+00*/
Related
Commands
:CHANnel<n>:SCALe
:CHANnel<n>:UNITs
:MATH:OPERator
:TIMebase[:MAIN]:SCALe

Rigol DS1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Interface	USB Host, USB Device, LAN, AUX
Display	7 inch TFT LCD (800 x 480)
Trigger Types	Edge, Pulse, Video, Slope
Power Supply	100-240 V, 45-440 Hz
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
