Rigol DS1104Z Programming Guide

RIGOL Chapter 2 Command System
2-104 DS1000Z Programming Guide
:TRIGger:TIMeout (Option)
Command List:
 :TRIGger:TIMeout:SOURce
 :TRIGger:TIMeout:SLOPe
 :TRIGger:TIMeout:TIMe
:TRIGger:TIMeout:SOURce
Syntax :TRIGger:TIMeout:SOURce <source>
:TRIGger:TIMeout:SOURce?
Description
Set or query the trigger source in timeout trigger.
Parameter
Name
Type
Range
Default
<source>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel1
Return
Format
The query returns CHAN1, CHAN2, CHAN3 or CHAN4.
Example :TRIGger:TIMeout:SOURce CHANnel2
:TRIGger:TIMeout:SLOPe
Syntax :TRIGger:TIMeout:SLOPe <slope>
:TRIGger:TIMeout:SLOPe?
Description
Set or query the edge type in timeout trigger.
Parameter
Name
Type
Range
Default
<slope>
Discrete
{POSitive|NEGative|RFALl}
POSitive
Explanation  POSitive: start timing when the rising edge of the input signal passes through the
trigger level.
 NEGative: start timing when the falling edge of the input signal passes through the
trigger level.
 RFALl: start timing when any edge of the input signal passes through the trigger
level.
Return
Format
The query returns POS, NEG or RFAL.
Example
:TRIGger:TIMeout:SLOPe NEGative

Rigol DS1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Interface	USB Host, USB Device, LAN, AUX
Display	7 inch TFT LCD (800 x 480)
Trigger Types	Edge, Pulse, Video, Slope
Power Supply	100-240 V, 45-440 Hz
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
