Rigol DS1104Z Programming Guide

Chapter 2 Command System RIGOL
DS1000Z Programming Guide 2-103
:TRIGger:DURATion:TLOWer
Syntax :TRIGger:DURATion:TLOWer <NR3>
:TRIGger:DURATion:TLOWer?
Description
Set or query the duration time lower limit in duration trigger. The default unit is s.
Parameter
Name
Type
Range
Default
<NR3>
Real
8ns to 9.99s
1μs
Explanation This command is available when the trigger condition (:TRIGger:DURATion:WHEN) is
GREater or GLESs.
Return
Format
The query returns the duration time lower limit in scientific notation.
Example
:TRIGger:DURATion:TLOWer 0.000003 /*Set the duration time lower limit to 3μs*/
:TRIGger:DURATion:TLOWer? /*The query returns 3.000000e-06*/
Related
Commands
:TRIGger:DURATion:WHEN
:TRIGger:DURATion:TUPPer

Rigol DS1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Interface	USB Host, USB Device, LAN, AUX
Display	7 inch TFT LCD (800 x 480)
Trigger Types	Edge, Pulse, Video, Slope
Power Supply	100-240 V, 45-440 Hz
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
