Rigol DS1104Z Programming Guide

RIGOL Chapter 2 Command System
2-70 DS1000Z Programming Guide
[:SOURce[<n>]]:FUNCtion:RAMP:SYMMetry
Syntax [:SOURce[<n>]]:FUNCtion:RAMP:SYMMetry <val>
[:SOURce[<n>]]:FUNCtion:RAMP:SYMMetry?
Description Set or query the ramp symmetry (the percentage that the rising period takes up in the
whole period) of the specified source channel. The default unit is %.
Parameter
Name
Type
Range
Default
[<n>] Discrete {1|2}
If omitted, the operation is
performed on source 1 by
default
<val> Real 0 to 100 10
Return
Format
The query returns the symmetry in scientific notation, such as 5.000000e+01.
Example
:FUNCtion:RAMP:SYMMetry 50
Related
Command
[:SOURce[<n>]]:FUNCtion[:SHAPe]
[:SOURce[<n>]]:VOLTage[:LEVel][:IMMediate][:AMPLitude]
Syntax [:SOURce[<n>]]:VOLTage[:LEVel][:IMMediate][:AMPLitude] <Amplitude>
[:SOURce[<n>]]:VOLTage[:LEVel][:IMMediate][:AMPLitude]?
Description
Set or query the output amplitude of the specified source channel. The default unit is Vpp.
Parameter
Name
Type
Range
Default
[<n>] Discrete {1|2}
If omitted, the operation is
performed on source 1 by
default
<Ampliude> Real
Related to the output
impedance:
HighZ: 20mVpp to 5Vpp
50Ω: 10mVpp to 2.5Vpp
1Vpp
Explanation You can use the [:SOURce[<n>]]:OUTPut[<n>]:IMPedance command to set the output
impedance.
Return
Format
The query returns the amplitude in scientific notation, such as 1.0000000e+00.
Example :VOLTage 2

Rigol DS1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Interface	USB Host, USB Device, LAN, AUX
Display	7 inch TFT LCD (800 x 480)
Trigger Types	Edge, Pulse, Video, Slope
Power Supply	100-240 V, 45-440 Hz
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
