Chapter 2 Command System RIGOL
DS1000Z Programming Guide 2-83
:TRIGger Commands
The :TRIGger commands are used to set the trigger system of the oscilloscope.
Command List:
 :TRIGger:MODE
 :TRIGger:COUPling
 :TRIGger:STATus?
 :TRIGger:SWEep
 :TRIGger:HOLDoff
 :TRIGger:NREJect
 :TRIGger:EDGe
 :TRIGger:PULSe
 :TRIGger:SLOPe
 :TRIGger:VIDeo
 :TRIGger:PATTern
 :TRIGger:DURATion
 :TRIGger:TIMeout (Option)
 :TRIGger:RUNT (Option)
 :TRIGger:WINDows (Option)
 :TRIGger:DELay (Option)
 :TRIGger:SHOLd
 :TRIGger:NEDGe (Option)
 :TRIGger:RS232 (Option)
 :TRIGger:IIC (Option)
 :TRIGger:SPI (Option)
:TRIGger:MODE
Syntax :TRIGger:MODE <mode>
:TRIGger:MODE?
Description
Select or query the trigger type.
Parameter
Name Type Range Default
<mode> Discrete {EDGE|PULSe|RUNT|WIND|NEDG|SLOPe|VIDeo|
PATTern|DELay|TIMeout|DURation|SHOLd|RS232
|IIC|SPI}
EDGE
Return
Format
The query returns EDGE, PULS, RUNT, WIND, NEDG, SLOP, VID, PATT, DEL, TIM, DUR,
SHOL, RS232, IIC or SPI.
Example
:TRIGger:MODE SLOPe

Rigol DS1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Interface	USB Host, USB Device, LAN, AUX
Display	7 inch TFT LCD (800 x 480)
Trigger Types	Edge, Pulse, Video, Slope
Power Supply	100-240 V, 45-440 Hz
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
