Rigol DS1104Z Programming Guide

RIGOL Chapter 2 Command System
2-58 DS1000Z Programming Guide
:MEASure:SETup:MIN
Syntax :MEASure:SETup:MIN <value>
:MEASure:SETup:MIN?
Description Set or query the lower limit of the threshold in the time, delay and phase measurements.
The default unit is %.
Parameter
Name
Type
Range
Default
<value>
Integer
5 to 93
10
Explanation  The upper limit, middle point and lower limit of the threshold (expressed in %) are
used to define the time, delay and phase parameters. Setting these values will affect
the measurement results of the time, delay and phase parameters.
 Setting the lower limit greater than the middle point will automatically increase the
middle point to keep it greater than the upper limit.
Return
Format
The query returns an integer between 5 and 93.
Example
:MEASure:SETup:MIN 93
Related
Commands
:MEASure:SETup:MAX
:MEASure:SETup:MID
:MEASure:ITEM
:MEASure:SETup:PSA
Syntax :MEASure:SETup:PSA <source>
:MEASure:SETup:PSA?
Description
Set or query source A of the Phase 1→2
and Phase 1→2 measurements.
Parameter
Name
Type
Range
Default
<source>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel1
Return
Format
The query returns CHAN1, CHAN2, CHAN3 or CHAN4.
Example
:MEASure:SETup:PSA CHANnel1
Related
Command
:MEASure:ITEM

Rigol DS1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Interface	USB Host, USB Device, LAN, AUX
Display	7 inch TFT LCD (800 x 480)
Trigger Types	Edge, Pulse, Video, Slope
Power Supply	100-240 V, 45-440 Hz
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
