Chapter 2 Command System RIGOL
DS1000Z Programming Guide 2-59
:MEASure:SETup:PSB
Syntax :MEASure:SETup:PSB <source>
:MEASure:SETup:PSB?
Description
Set or query source B of the Phase 1
→
2 and Phase 1
→
2 measurements.
Parameter
Name
Type
Range
Default
<source>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel2
Return
Format
The query returns CHAN1, CHAN2, CHAN3 or CHAN4.
Example
:MEASure:SETup:PSB CHANnel1
Related
Command
:MEASure:ITEM
:MEASure:SETup:DSA
Syntax :MEASure:SETup:DSA <source>
:MEASure:SETup:DSA?
Description
Set or query source A of the Delay 1→2
and Delay 1→2 measurements.
Parameter
Name
Type
Range
Default
<source>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel1
Return
Format
The query returns CHAN1, CHAN2, CHAN3 or CHAN4.
Example
:MEASure:SETup:DSA CHANnel1
Related
Command
:MEASure:ITEM
:MEASure:SETup:DSB
Syntax :MEASure:SETup:DSB <source>
:MEASure:SETup:DSB?
Description
Set or query source B of the Delay 1→2
and Delay 1→2 measurements.
Parameter
Name
Type
Range
Default
<source>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel2
Return
Format
The query returns CHAN1, CHAN2, CHAN3 or CHAN4.
Example
:MEASure:SETup:DSB CHANnel1
Related
Command
:MEASure:ITEM
