RIGOL Chapter 2 Command System
2-84 DS1000Z Programming Guide
:TRIGger:COUPling
Syntax :TRIGger:COUPling <couple>
:TRIGger:COUPling?
Description
Select or query the trigger coupling type.
Parameter
Name
Type
Range
Default
<couple>
Discrete
{AC|DC|LFReject|HFReject}
DC
Explanation  This command is only applicable to the edge trigger.
 AC: block all the DC components and attenuate signals lower than 75 kHz.
 DC: allow DC and AC components into the trigger path.
 LFReject: block the DC components and reject the low frequency components (lower
than 75 kHz).
 HFReject: reject the high frequency components (higher than 75 kHz).
Return
Format
The query returns AC, DC, LFR or HFR.
Example
:TRIGger:COUPling LFReject
:TRIGger:STATus?
Syntax :TRIGger:STATus?
Description
Query the current trigger status.
Return
Format
The query returns TD, WAIT, RUN, AUTO or STOP.
:TRIGger:SWEep
Syntax :TRIGger:SWEep <sweep>
:TRIGger:SWEep?
Description
Set or query the trigger mode.
Parameter
Name Type Range Default
<sweep>
Discrete
{AUTO|NORMal|SINGle}
AUTO
Explanation  AUTO: auto trigger. No matter whether the trigger condition is met, there is always
waveform display.
 NORMal: normal trigger. Display waveform when the trigger condition is met;
otherwise, the oscilloscope holds the original waveform and waits for the next trigger.
 SINGle: single trigger. The oscilloscope waits for a trigger and displays the waveform
when the trigger condition is met and then stops.
Return
Format
The query returns AUTO, NORM or SING.
Example
:TRIGger:SWEep SINGle
