Rigol DS1104Z Programming Guide

Chapter 2 Command System RIGOL
DS1000Z Programming Guide 2-43
:MATH:OPTion:END
Syntax :MATH:OPTion:END <end>
:MATH:OPTion:END?
Description
Set or query the end point of the waveform math operation.
Parameter
Name
Type
Range
Default
<end>
Discrete
(Start point currently set+1) to 1199
1199
Explanation  This command is invalid for the FFT operation. Sending this command will modify the
end points of all the operations (except FFT).
 The horizontal axis of the source selected is equally divided into 1200 parts, in which
the leftmost is 0 and the rightmost is 1199.
Return
Format
The query returns an integer.
Example
:MATH:OPTion:END 200
Related
Command
:MATH:OPTion:STARt
:MATH:OPTion:INVert
Syntax :MATH:OPTion:INVert <bool>
:MATH:OPTion:INVert?
Description Enable or disable the inverted display mode of the operation result, or query the inverted
display mode status of the operation result.
Parameter
Name
Type
Range
Default
<bool>
Bool
{{0|OFF}|{1|ON}}
0|OFF
Explanation  This command is invalid for the FFT operation. Sending this command will modify the
inverted display mode status of all the operations (except FFT).
 This command has the same function as the :MATH:INVert command.
Return
Format
The query returns 0 or 1.
Example
:MATH:OPTion:INVert ON
Related
Command
:MATH:INVert
