Rigol DS1104Z Programming Guide

RIGOL Chapter 2 Command System
2-88 DS1000Z Programming Guide
:TRIGger:PULSe
Command List:
 :TRIGger:PULSe:SOURce
 :TRIGger:PULSe:WHEN
 :TRIGger:PULSe:WIDTh
 :TRIGger:PULSe:UWIDth
 :TRIGger:PULSe:LWIDth
 :TRIGger:PULSe:LEVel
:TRIGger:PULSe:SOURce
Syntax :TRIGger:PULSe:SOURce <source>
:TRIGger:PULSe:SOURce?
Description
Set or query the trigger source in pulse width trigger.
Parameter
Name
Type
Range
Default
<source> Discrete {CHANnel1|CHANnel2|CHANnel3|CHANnel4} CHANnel1
Return
Format
The query returns CHAN1, CHAN2, CHAN3 or CHAN4.
Example :TRIGger:PULSe:SOURce CHANnel1 /*Set the trigger source to CH1*/
:TRIGger:PULSe:WHEN
Syntax :TRIGger:PULSe:WHEN <when>
:TRIGger:PULSe:WHEN?
Description
Set or query the trigger condition in pulse width trigger.
Parameter
Name
Type
Range
Default
<when>
Discrete
{PGReater|PLESs|NGReater|NLESs|PGLess|NGLess}
PGReater
Explanation  PGReater/PLESs: you need to specify a pulse width (refer
to
:TRIGger:PULSe:WIDTh). The oscilloscope triggers when the positive pulse width
of the input signal is greater/lower than the specified Pulse Width.
 NGReater/NLESs: you need to specify a pulse width (refer
to
:TRIGger:PULSe:WIDTh). The oscilloscope triggers when the negative pulse width
of the input signal is greater/lower than the specified Pulse Width.
 PGLess/NGLess: you need to specify an upper (refer to
:TRIGger:PULSe:UWIDth)
and a lower (refer to
:TRIGger:PULSe:LWIDth) pulse width. The oscilloscope triggers
when the positive/negative pulse width of the input signal is greater than the
specified lower pulse width and lower than the upper pulse width.
Return
Format
The query returns PGR, PLES, NGR, NLES, PGL or NGL.
Example
:TRIGger:PULSe:WHEN NLESs /*Set the trigger condition to NLESs*/
Related
Commands
:TRIGger:PULSe:WIDTh
:TRIGger:PULSe:UWIDth
:TRIGger:PULSe:LWIDth

Rigol DS1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Interface	USB Host, USB Device, LAN, AUX
Display	7 inch TFT LCD (800 x 480)
Trigger Types	Edge, Pulse, Video, Slope
Power Supply	100-240 V, 45-440 Hz
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
