Rigol DS1104Z Programming Guide

RIGOL Chapter 2 Command System
2-90 DS1000Z Programming Guide
:TRIGger:PULSe:LWIDth
Syntax :TRIGger:PULSe:LWIDth <width>
:TRIGger:PULSe:LWIDth?
Description
Set or query the lower pulse width in pulse width trigger. The default unit is s.
Parameter
Name
Type
Range
Default
<width>
Real
8ns to 9.99s
992ns
Explanation This command is available when the trigger condition (refer to :TRIGger:PULSe:WHEN) is
PGLess and NGLess.
Return
Format
The query returns the lower pulse width in scientific notation.
Example
:TRIGger:PULSe:LWIDth 0.000003 /*Set the lower pulse width to 3μs*/
:TRIGger:PULSe:LWIDth? /*The query returns 3.000000e-06*/
Related
Commands
:TRIGger:PULSe:WHEN
:TRIGger:PULSe:UWIDth
:TRIGger:PULSe:LEVel
Syntax :TRIGger:PULSe:LEVel <level>
:TRIGger:PULSe:LEVel?
Description Set or query the trigger level in pulse width trigger. The unit is the same as the current
amplitude unit.
Parameter
Name
Type
Range
Default
<level> Real
(± 5 × VerticalScale from the screen center) -
OFFSet
0
Explanation For VerticalScale, refer to the :CHANnel<n>:SCALe command. For OFFSet, refer to
the :CHANnel<n>:OFFSet command.
Return
Format
The query returns the trigger level in scientific notation.
Example
:TRIGger:PULSe:LEVel 0.16 /*Set the trigger level to 160mV*/
:TRIGger:PULSe:LEVel? /*The query returns 1.600000e-01*/
Related
Commands
:CHANnel<n>:SCALe
:CHANnel<n>:OFFSet

Rigol DS1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Interface	USB Host, USB Device, LAN, AUX
Display	7 inch TFT LCD (800 x 480)
Trigger Types	Edge, Pulse, Video, Slope
Power Supply	100-240 V, 45-440 Hz
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
