:MASK Commands
The :MASK commands are used to set and query the pass/fail test parameters.
Command List:
 :MASK:ENABle
 :MASK:SOURce
 :MASK:OPERate
 :MASK:MDISplay
 :MASK:SOOutput
 :MASK:OUTPut
 :MASK:X
 :MASK:Y
 :MASK:CREate
 :MASK:PASSed?
 :MASK:FAILed?
 :MASK:TOTal?
 :MASK:RESet
:MASK:ENABle
Syntax :MASK:ENABle <bool>
:MASK:ENABle?
Description
Enable or disable the pass/fail test or query the status of the past/fail test.
Parameter
Name
Type
Range
Default
<bool>
Bool
{{0|OFF}|{1|ON}}
0|OFF
Explanation The pass/fail test is invalid in the following conditions: the horizontal timebase is XY or
ROLL, in the slow sweep mode (namely when the horizontal timebase is YT, the horizontal
timebase is set to 200ms/div or slower) as well as during waveform record.
Return
Format
The query returns 0 or 1.
Example
:MASK:ENABle ON
