Rigol DS1104Z Programming Guide

RIGOL Chapter 2 Command System
2-112 DS1000Z Programming Guide
:TRIGger:WINDows:ALEVel
Syntax :TRIGger:WINDows:ALEVel <level>
:TRIGger:WINDows:ALEVel?
Description Set or query the trigger level upper limit in windows trigger. The unit is the same as the
current amplitude unit.
Parameter
Name
Type
Range
Default
<level> Real (± 5 × VerticalScale from the screen center) - OFFSet 2V
Explanation For VerticalScale, refer to :CHANnel<n>:SCALe. For OFFSet, refer
to :CHANnel<n>:OFFSet.
Return
Format
The query returns the trigger level upper limit in scientific notation.
Example
:TRIGger:WINDows:ALEVel 0.16 /*Set the trigger level upper limit to 160mV*/
:TRIGger:WINDows:ALEVel? /*The query returns 1.600000e-01*/
Related
Commands
:CHANnel<n>:SCALe
:CHANnel<n>:OFFSet
:TRIGger:WINDows:BLEVel
Syntax :TRIGger:WINDows:BLEVel <level>
:TRIGger:WINDows:BLEVel?
Description Set or query the tigger level lower limit in windows trigger. The unit is the same as the
current amplitude unit.
Parameter
Name Type Range Default
<level>
Real
(± 5 × VerticalScale from the screen center) - OFFSet
0
Explanation For VerticalScale, refer to :CHANnel<n>:SCALe. For OFFSet, refer
to :CHANnel<n>:OFFSet.
Return
Format
The query returns the tigger level lower limit in scientific notation.
Example
:TRIGger:WINDows:BLEVel 0.05
Related
Commands
:CHANnel<n>:SCALe
:CHANnel<n>:OFFSet

Rigol DS1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Interface	USB Host, USB Device, LAN, AUX
Display	7 inch TFT LCD (800 x 480)
Trigger Types	Edge, Pulse, Video, Slope
Power Supply	100-240 V, 45-440 Hz
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
