RIGOL Chapter 2 Command System
2-114 DS1000Z Programming Guide
:TRIGger:DELay:SLOPB
Syntax :TRIGger:DELay:SLOPB <slope>
:TRIGger:DELay:SLOPB?
Description
Set or query the edge type of the trigger source B in delay trigger.
Parameter
Name
Type
Range
Default
<slope>
Discrete
{POSitive|NEGative}
POSitive
Return
Format
The query returns POS or NEG.
Example
:TRIGger:DELay:SLOPB NEGative
:TRIGger:DELay:TYPe
Syntax :TRIGger:DELay:TYPe <type>
:TRIGger:DELay:TYPe?
Description
Set or query the delay type in delay trigger.
Parameter
Name Type Range Default
<type>
Discrete
{GREater|LESS|GLESs |GOUT}
GREater
Explanation  GREater: trigger when the time difference (
△
T) between the specified edges of tigger
source A and tigger source B is greater than the preset time limit.
 LESS: trigger when the time difference (△T) between the specified edges of tigger
source A and tigger source B is lower than the preset time limit.
 GLESs: trigger when the time difference (△T) between the specified edges of tigger
source A and tigger source B is greater than the lower limit of the preset time and
lower than the upper limit of the preset time. Note that the time lower limit must be
lower than the time upper limit.
 GOUT: trigger when the time difference (△T) between the specified edges of tigger
source A and tigger source B is lower than the lower limit of the preset time or
greater than the upper limit of the preset time. Note that the time lower limit must be
lower than the time upper limit.
Return
Format
The query returns GOUT, GRE, LESS or GLES.
Example
:TRIGger:DELay:TYPe GOUT
Related
Commands
:TRIGger:DELay:TUPPer
:TRIGger:DELay:TLOWer

Rigol DS1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Interface	USB Host, USB Device, LAN, AUX
Display	7 inch TFT LCD (800 x 480)
Trigger Types	Edge, Pulse, Video, Slope
Power Supply	100-240 V, 45-440 Hz
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
