General| Bandwidth | 100 MHz |
|---|---|
| Channels | 4 |
| Sample Rate | 1 GSa/s |
| Waveform Capture Rate | 30, 000 wfms/s |
| Vertical Sensitivity | 1 mV/div to 10 V/div |
| Time Base Range | 5 ns/div to 50 s/div |
| Vertical Resolution | 8 bits |
| Interface | USB Host, USB Device, LAN, AUX |
| Display | 7 inch TFT LCD (800 x 480) |
| Trigger Types | Edge, Pulse, Video, Slope |
| Power Supply | 100-240 V, 45-440 Hz |
| Memory Depth | 24 Mpts (Single Channel), 12 Mpts (Dual Channel) |
