Rigol DS1104Z Programming Guide

RIGOL Chapter 2 Command System
2-24 DS1000Z Programming Guide
:CURSor:TRACk:BYValue?
Syntax
:CURSor:TRACk:BYValue?
Description Query the Y value of cursor B in the track cursor measurement mode. The unit is the same
as the channel unit currently selected.
Return
Format
The query returns the Y value of cursor B in scientific notation.
Example
:CURSor:TRACk:BYValue? /*The query returns -4.000000e-06*/
Related
Commands
:CHANnel<n>:UNITs
:CURSor:TRACk:BY?
:CURSor:TRACk:XDELta?
Syntax
:CURSor:TRACk:XDELta?
Description Query the difference between the X values of cursor A and cursor B (BX-AX) in the track
cursor measurement mode. The default unit is s.
Return
Format
The query returns the difference in scientific notation.
Example :CURSor:TRACk:XDELta? /*The query returns 6.120000e-06*/
Related
Commands
:CURSor:TRACk:AX
:CURSor:TRACk:BX
:CURSor:TRACk:IXDELTA?
Syntax
:CURSor:TRACk:IXDELTA?
Description Query the reciprocal of the absolute value of the difference between the X values of cursor
A and cursor B (1/|dX|) in the track cursor measurement mode. The default unit is Hz.
Return
Format
The query returns 1/|dX| in scientific notation.
Example
:CURSor:TRACk:IXDELTA? /*The query returns 1.120000e+05*/
Related
Commands
:CURSor:TRACk:AX
:CURSor:TRACk:BX

Rigol DS1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Interface	USB Host, USB Device, LAN, AUX
Display	7 inch TFT LCD (800 x 480)
Trigger Types	Edge, Pulse, Video, Slope
Power Supply	100-240 V, 45-440 Hz
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
