Wherein,
Phase
denotes “Phase 1→2 ” or “Phase 1→2 ”,
Delay
denotes “Delay 1→2 ” or
“Delay 1→2
” and
1Period
denotes the period of source 1.
Source 1
Source 2
Period
Delay
 Voltage Parameters
Vmax:
the voltage value from the highest point of the waveform to the GND.
Vmin:
the voltage value from the lowest point of the waveform to the GND.
Vpp:
the voltage value from the highest point to the lowest point of the waveform.
Vtop:
the voltage value from the flat top of the waveform to the GND.
Vbase:
the voltage value from the flat base of the waveform to the GND.
Vamp:
the voltage value from the top of the waveform to the base of the waveform.
Vavg:
the arithmetic average value on the whole waveform or on the gating area.
i
x
Average
n
=
∑
, wherein,
i
x
is the
ith
point being measured,
n
is the number of
points being measured.
Vrms:
the root mean square value on the whole waveform or the gating area.
2
1
n
i
i
x
RMS
n
=
=
∑
, where,
i
x
is the
ith
point being measured,
n
is the number of
points being measured.
Overshoot:
the ratio of the difference between the maximum value and top value of the waveform
to the amplitude value.
Preshoot:
the ratio of the difference between the minimum value and base value of the waveform
to the amplitude value.
Preshoot
Overshoot
Vamp
Vmax
Vmin
Vpp
Vtop
Vbase

Rigol DS1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Interface	USB Host, USB Device, LAN, AUX
Display	7 inch TFT LCD (800 x 480)
Trigger Types	Edge, Pulse, Video, Slope
Power Supply	100-240 V, 45-440 Hz
Memory Depth	24 Mpts (Single Channel), 12 Mpts (Dual Channel)
