View the status for individual partition(s) or all partitions to which the keypad is assigned
(according to your user authority level).
➢ To view partition status for the keypad-assigned partition:
1. At the keypad, press the scroll button to view all status information for the first block of
partitions (partitions 1—10), such as R (ready to arm) or NR (not ready to arm).
2. Press scroll again to view the status for the next block of partitions –you can repeat this
to view the status of all partitions (32 maximum).
➢ To view partition status for all partitions:
1. At the keypad, enter your Grand Master or user code, and then press OK.
2. Scroll to View and then press OK.
3. Scroll to Part. Status and then press OK.
4. While scrolling through the partitions, for each you can view its status, such as R (ready
to arm) or NR (not ready to arm).
Viewing IP Address
View the IP address of the system.
➢ To view the IP address:
1. At the keypad, enter your Grand Master code, and then press OK.
2. Scroll to View and then press OK.
3. Scroll to View IP Address and then press OK; the IP address displays.
Viewing Service Information
View the following types of service information (per user authority level):
• Installer/technician information
• System Version
• Serial Number
• Panel ID
