Risco LightSYS Plus - Elegant Keypad Indicators; Remote Control Indicators; 8-Button Remote Control Indicators; 4-Button Panda Keyfob Indicators

01/2022
Page 89
5IN2933
Elegant Keypad Indicators
POWER
On: Power OK.
Off: No power
Rapid flash: System trouble.
Slow flash: System is
programming
READY
On: Ready to arm
Off: Not ready to arm
Slow flash: Ready to
arm with open
Exit/Entry zone
ARM
On: System in fully armed mode
Off: System disarmed
Rapid flash: Alarm
Slow flash: System in Exit Delay
PARTIAL (STAY) ARM
/ BYPASS
On: System is in partially-
armed or zone-bypass mode
Off: No bypassed zones
TAMPER
On: Tamper alarm
Off: No tamper alarm
FIRE
On: Fire alarm
Off: No fire alarm
Flash: Fire alarm trouble (fire
circuit trouble)
Remote Control Indicators
8-Button Remote Control Indicators
Operation
LED for Send Commands
LED for Receive Status
Full Arming
Green*
Red
Partial Arming
Green*
Orange
Disarming
Green*
Green
Alarm
Green*
Flashing LED
* If the LED changes to orange, it indicates the remote control battery is low.
4-Button Panda Keyfob Indicators
Operation
LED for Send Commands
LED for Receive Status
Full Arming
Green*
Red
Partial Arming
Green*
Orange
Disarming
Green*
Green
Alarm
Green*
Flashing LED
UO activation
Green*
Blinks according to panel status
* If the LED changes to orange, it indicates the remote control battery is low.
