Roche Diagnostics
Operatorโ€™s Manual ยท Version 3.4 F-59
Cedex Bio analyzer 15 ISE maintenance
ISE maintenance actions
Removing the tubing
7
Open the cover of the peristaltic pump.
8
Push the pump towards the back of the analyzer.
9
Disengage the tube connector plate.
10
Remove the ISE pump tubing set.
A Cover of peristaltic pump
Figure F-10
A
Connector plate
Figure F-11
A
ISE pump tubing set
Figure F-12
A
A
A
