100 Rockwell Automation Publication ICSTT-RM448M-EN-P - February 2021

Chapter 5 Install the AADvance System

System powered devices

The above circuit is appropriate for devices that are powered by the system.

The channel will pass a requested current between 0mA and 24mA. The field

device could also be connected between the 24V supply and the Loop Plus

terminal.

IMPORTANT

If the 24 V supply is shared between channels or between

modules, the field loops will not be isolated from each other.
