Rockwell Automation Publication ICSTT-RM448M-EN-P - February 2021 119
Chapter 6 System Startup
Processor Firmware
Upgrades
The firmware revision in the processor modules can be checked using RSLinx®
RSWho. If the firmware needs to be upgraded, this can be done using
ControlFLASH.
Required software:
• ControlFLASH version 13 or later
• RSLinx Classic Lite version 3.90.00 or later
Required ControlFLASH files for the T9110 Processor Module:
• T9110 Normal Mode ControlFLASH.
• T9110 Recovery Mode ControlFLASH.
The processor module contains two sets of firmware. The normal firmware is
the operational firmware and allows the application to execute and
communicates with the I/O modules. The recovery firmware is used to update
the firmware in the processor module and help diagnose problems. The
normal and recovery firmware are updated with separate ControlFLASH files.
Before starting check that:
• ControlFLASH and RSLinx® Gateway has been installed and configured
• The PC is connected via Ethernet to the processor module
• The correct ControlFLASH file for the processor module has been
installed
• The processor modules are in recovery mode - restart the modules and
press the Fault Reset button, hold until the Aux LED changes to amber
Dual and triple processor modules are updated at the same time.
Update procedure:
• Run the ControlFLASH program
• Select the T9110 module from the list
• Browse to the T9110 module and select it
• Select the version of firmware to be sent to the module
• Update the module
5.
After approximately 3 seconds the module will now make the following status indications:
Healthy GREEN
Ready GREEN
Run AMBER
Channel 1 – 8 Off
6. Push the Fault Reset button on the processor module and the Run indication goes GREEN.
7.
The module will now be on-line with the following status indications:
Healthy GREEN
Ready GREEN
Run GREEN
Channel 1 – 8 Dependent on channel status
8. If the module fails to educate and go on-line replace the module.
Table 15 - Second or third Module of a Group Installation Procedure
Step Task
