Chapter 2 The AADvance Safety Controller
is an output configured to go to a specific value, or configured to hold last
state)
Safety System Certification The AADvance Controller is certified by independent certifying bodies. Refer
to the certificate for details of the standards included in the certification.
Performance and Electrical
Specifications
Scan Times
The controller processing scan times listed in the table are taken from a test
system which used only production modules. The tests which were used to
measure the scan times did not measure the effects of logic complexity and
communications loading.
Table 1 - Controller Performance and Electrical Specifications
Attribute Value
Performance Characteristics
Safety Integrity Level
IEC 61508 SIL 2
IEC 61508 SIL 3
(depending on processor and I/O module configuration)
Safety level Degradation 1oo1D, 1oo2D, 2oo3D
Processor Modules supported Three
I/O Modules supported 48 (8 or 16 channels modules)
Safety Accuracy Limit:
Digital inputs
Analogue inputs
1.0 Vdc
200 µA
Sequence of Event Resolution
Processor Module (for internal Variables):
Event Resolution
Time Stamp Accuracy
Digital Input Module:
Event Resolution
Time Stamp Accuracy
1 ms
Application Scan
1 ms
10 ms
Electrical Characteristics
Supply voltage Redundant 24 Vdc nominal, 18 Vdc to 32 Vdc range
Channel isolation (channel to channel and channel
to chassis
Maximum withstanding ± 1.5 kVdc withstand for 1 minute.
IMPORTANT
Overall system power consumption, heat dissipation and weight
can be estimated using the values given in the heat dissipation
and weight data tables shown in this manual.
