116 Rockwell Automation Publication ICSTT-RM448M-EN-P - February 2021
Chapter 6 System Startup
System Configuration and Application Programming
When the hardware is installed and running, set up the system configuration
by using the AADvance Workbench software or AADvance-Trusted SIS
Workstation software.
Refer to the applicable software publication for system configuration
instructions:
• AADvance Controller Configuration Guide Workbench 1.x, publication
ICSTT-RM405
• AADvance Controller Configuration Guide Workbench 2.x, publication
ICSTT-RM458
• AADvance-Trusted SIS Workstation Software User Guide, publication
ICSTT-UM002
Processor Module Startup
Process
NOTE When inserting more than one processor module they MUST be
inserted one at a time and the module be allowed to educate (in
the case of a 2nd and 3rd processor).
Table 12 - Single Processor Module Installation Procedure (New Processor Module)
Step Task
1.
With the power switched on place the processor module into slot A on the Base Unit connectors
and push the module home until the connectors are fully mated. Turn the locking screw and lock
the module in position.
2.
All LEDs are off and after applying power the processor will show the following status
indications:
Healthy
Flashes RED for a second then goes GREEN as the module boots up (10-20
seconds)
Ready Will stay OFF as the module boots up (10 to 20 seconds) then goes RED
Run Will stay OFF as the Module boots up (10 to 20 seconds) then goes RED
System Healthy Will stay OFF as the Module boots up (10 to 20 seconds) then goes GREEN
Force
Will stay OFF as the Module boots up (10 to 20 seconds) then stays OFF until
the module has educated.
Aux
Will stay OFF as the Module boots up (10 to 20 seconds) then depends on data
connection.
Serial 1
Will stay OFF as the Module boots up (10 to 20 seconds) then depends on data
connection
Serial 2
Will stay OFF as the Module boots up (10 to 20 seconds) then depends on data
connection
Ethernet 1
Will stay OFF as the Module boots up (10 to 20 seconds) then depends on data
connection
Ethernet 2
Will stay OFF as the Module boots up (10 to 20 seconds) then depends on data
connection
To Next Page
