96 Rockwell Automation Publication ICSTT-RM448M-EN-P - February 2021

Chapter 5 Install the AADvance System

Connections to T9832/T9833 Isolated Analogue Input TA — 16 Channel TMR

• Apply a minimum tightening torque of 0.5 Nm (0.37 ft. lb.) to the

terminal screws.

Recommended Field Circuit for Digital Outputs

This circuit is applicable for simplex and dual configurations of digital output

modules. The two 10 A fuses shown are included on the termination assembly

within the controller. The 5 A fuses satisfy UL508 requirements for digital

output field supplies, see illustration below:
