56 Rockwell Automation Publication ICSTT-RM448M-EN-P - February 2021
Chapter 4 Before You Begin
Controller Mounting
An AADvance controller and I/O bases can be mounted using one of two
methods:
• A pair of parallel TS35 DIN rails.
• Panel mounted using three holes on each base.
Free Space around the Controller
Whichever mounting method is used the minimum depth from the rear
mounting panel to the front panel and space around the base units are shown
in the illustration, if you wish to mount the controller on DIN rails, increase
this allowance by the increased depth of the DIN rails. The DIN rails must be
TS35 rail, which is a 35mm × 7.5mm standard symmetric rail.
You must have sufficient free space around the base units to allow for the
following:
• Space above, to adjust and install field wiring.
• Space below, to let modules fit and to be able to hold a module during
removal.
• Space to the right of the last base unit in the row, to move an I/O base
unit during assembly or if you are installing a new base unit.
AVERTISSEMENT: RISQUE D’EXPLOSION
Ne pas connecter ou déconnecter l’équipement alors qu’il est sous
tension, sauf si l’environnement est exempt de concentrations
inflammables ou équivalente
WARNING: Substitution of any component may impair suitability for Class I,
Division 2 or equivalent.
AVERTISSEMENT: La substitution de composants peut rendre impropre à
l’utilisation en Classe I, Division 2 ou équivalente.
CAUTION: For AADvance modules T9110, T9801,- T9803, T9831- T9833,
T9851, T9852, T9892, T9881 and T9882 a disconnect suitable for the location
where they are installed shall be provided to allow for removal of power from
the fuses before replacement.
ATTENTION: Pour les modules AADvance T9110, T9801,- T9803, T9831-
T9833, T9851, T9852, T9892, T9881 et T9882, un sectionneur adapté à
l’environnement où ils sont installés devra être fourni pour couper
l’alimentation en amont des fusibles avant leur remplacement.
