48 Rockwell Automation Publication ICSTT-RM448M-EN-P - February 2021
Chapter 2 The AADvance Safety Controller
• Browse to the T9110 Processor Module
• Select the version of the firmware to be installed (NOTE: it may be
necessary to tick the “Show all versions” checkbox to see the version
required)
• Update the module
• The firmware will be downloaded and stored on the module – this will
take approximately 5 minutes
• The modules will be rebooted to confirm the firmware has been updated
successfully
Refer to document 1756-UM105 ControlFLASH firmware Upgrade Kit User
Manual in the Literature Library for detailed instructions for using
ControlFLASH.
Ethernet Communication Protocols
AADvance Ethernet ports are used to support several transport layer services;
these services are listed in the following table:
NOTE When updating the firmware, it is recommended that RSWho is
not actively browsing the T9110 Processor module.
Protocol Port Number Availability Purpose
TCP 502 When configured MODBUS slave
TCP 1132 Always available
AADvance, application downloads, update,
monitor, SoE, and so forth
TCP 10001- 10006
When configured (and the
application is stopped)
Transparent Communications Interface (serial
tunnelling)
TCP 44818 Always available CIP™ Produce & Consume
TCP 55555 Always available Telnet (diagnostic interface)
UDP 123 When configured SNTP
UDP 1123,1124 Always available SNCP bindings
UDP 2010 Always available
Discovery and configuration protocol (DCP,
Rockwell Automation)
UDP 2222 When configured CIP produce and consume I/Os
UDP 5000
When at least one P2P
subnet is active on a
controller
Peer-to-peer
UDP 44818 Always available CIP produce and consume
